普罗米修斯docker 部署后遇见的问题

首先登陆服务器之后有容器cadvisor就无限制重启报错

shitou@aishitou:~$ sudo docker ps
CONTAINER ID   IMAGE                    COMMAND                  CREATED                                  STATUS                           PORTS                                                                   NAMES
ab357e46450f   grafana/grafana:latest   "/run.sh"                5 months ago                             Up 2 days                        0.0.0.0:3000->3000/tcp, [::]:3000->3000/tcp                             grafana
553e54dcef0d   prom/prometheus:latest   "/bin/prometheus --c…"   5 months ago                             Up 2 days                        0.0.0.0:9090->9090/tcp, [::]:9090->9090/tcp                             prometheus
eec3a45791bc   google/cadvisor:latest   "/usr/bin/cadvisor -…"   5 months ago                             Restarting (255) 2 seconds ago

shitou@aishitou:~/monitor$ cat docker-compose.yml
version: '3'

services:
  prometheus:
    image: prom/prometheus:latest
    container_name: prometheus
    restart: always
    volumes:
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
      - prometheus_data:/prometheus
    ports:
      - "9090:9090"
    networks:
      - monitor_net

  grafana:
    image: grafana/grafana:latest
    container_name: grafana
    restart: always
    environment:
      - GF_DEFAULT_LANGUAGE=zh-CN  # 强制中文界面
    volumes:
      - grafana_data:/var/lib/grafana
      - ./grafana/provisioning:/etc/grafana/provisioning  # 预配置目录
    ports:
      - "3000:3000"
    networks:
      - monitor_net
    depends_on:
      - prometheus

  cadvisor:
    image: docker.io/google/cadvisor:latest
    container_name: cadvisor
    restart: always
    volumes:
      - /:/rootfs:ro
      - /var/run:/var/run:ro
      - /sys:/sys:ro
      - /var/lib/docker/:/var/lib/docker:ro
    ports:
      - "8080:8080"
    networks:
      - monitor_net

volumes:
  prometheus_data:
  grafana_data:

networks:
  monitor_net:
    driver: bridge
shitou@aishitou:~/monitor$ cat
docker-compose.yml  grafana/            prometheus.yml
shitou@aishitou:~/monitor$ cat prometheus.yml
global:
  scrape_interval: 15s

scrape_configs:
  - job_name: 'prometheus'
    static_configs:
      - targets: ['prometheus:9090']  # 直接使用容器名访问

  - job_name: 'cadvisor'
    static_configs:
      - targets: ['cadvisor:8080']    # 直接使用容器名访问

shitou@aishitou:~/monitor$ cat docker-compose.yml
version: '3'

services:
  prometheus:
    image: prom/prometheus:latest
    container_name: prometheus
    restart: always
    volumes:
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
      - prometheus_data:/prometheus
    ports:
      - "9090:9090"
    networks:
      - monitor_net

  grafana:
    image: grafana/grafana:latest
    container_name: grafana
    restart: always
    environment:
      - GF_DEFAULT_LANGUAGE=zh-CN  # 强制中文界面
    volumes:
      - grafana_data:/var/lib/grafana
      - ./grafana/provisioning:/etc/grafana/provisioning  # 预配置目录
    ports:
      - "3000:3000"
    networks:
      - monitor_net
    depends_on:
      - prometheus

  cadvisor:
    image: docker.io/google/cadvisor:latest
    container_name: cadvisor
    restart: always
    privileged: true
    volumes:
      - /:/rootfs:ro
      - /var/run:/var/run:ro
      - /sys:/sys:ro
      - /var/lib/docker/:/var/lib/docker:ro
      - /dev/kmsg:/dev/kmsg:ro
    ports:
      - "8080:8080"
    networks:
      - monitor_net
    cap_add:  # 新增：赋予访问内核日志的权限
      - SYSLOG
volumes:
  prometheus_data:
  grafana_data:

networks:
  monitor_net:
    driver: bridge


shitou@aishitou:~/monitor$ sudo cp /etc/fstab /etc/fstab.v1
shitou@aishitou:~/monitor$ sudo rm /etc/fstab
shitou@aishitou:~/monitor$ sudo cp /etc/fstab.
fstab.bf  fstab.v1
shitou@aishitou:~/monitor$ sudo cp /etc/fstab.bf /etc/fstab
shitou@aishitou:~/monitor$ cat /etc/fstab
# /etc/fstab: static file system information.
#
# Use 'blkid' to print the universally unique identifier for a
# device; this may be used with UUID= as a more robust way to name devices
# that works even if disks are added and removed. See fstab(5).
#
# <file system> <mount point>   <type>  <options>       <dump>  <pass>
# / was on /dev/sda2 during curtin installation
/dev/disk/by-uuid/975f86b3-b8ea-4365-902d-5c61c0ad749c / ext4 defaults 0 1
# /boot was on /dev/sda3 during curtin installation
/dev/disk/by-uuid/069c7f52-682b-45f4-8c2e-2f2f38f9c60a /boot ext4 defaults 0 1
/dev/disk/by-uuid/8b865cd9-1d8f-48e5-bfe6-6a649909b853 none swap sw 0 0
# /boot/efi was on /dev/sda1 during curtin installation
/dev/disk/by-uuid/2D20-0B2E /boot/efi vfat defaults 0 1
shitou@aishitou:~/monitor$ cat /etc/fstab.
fstab.bf  fstab.v1
shitou@aishitou:~/monitor$ cat /etc/fstab.v1
# /etc/fstab: static file system information.
#
# Use 'blkid' to print the universally unique identifier for a
# device; this may be used with UUID= as a more robust way to name devices
# that works even if disks are added and removed. See fstab(5).
#
# <file system> <mount point>   <type>  <options>       <dump>  <pass>
# / was on /dev/sda2 during curtin installation
/dev/disk/by-uuid/975f86b3-b8ea-4365-902d-5c61c0ad749c / ext4 defaults 0 1
# /boot was on /dev/sda3 during curtin installation
/dev/disk/by-uuid/069c7f52-682b-45f4-8c2e-2f2f38f9c60a /boot ext4 defaults 0 1
/dev/disk/by-uuid/8b865cd9-1d8f-48e5-bfe6-6a649909b853 none swap sw 0 0
# /boot/efi was on /dev/sda1 during curtin installation
/dev/disk/by-uuid/2D20-0B2E /boot/efi vfat defaults 0 1
none  /sys/fs/cgroup/cpu  cgroup  defaults,cpu,cpuacct  0  0

修改为v2,

shitou@aishitou:~/monitor$ cat /etc/default/grub
# If you change this file, run 'update-grub' afterwards to update
# /boot/grub/grub.cfg.
# For full documentation of the options in this file, see:
#   info -f grub -n 'Simple configuration'

GRUB_DEFAULT=0
GRUB_TIMEOUT_STYLE=hidden
GRUB_TIMEOUT=0
GRUB_DISTRIBUTOR=`( . /etc/os-release; echo ${NAME:-Ubuntu} ) 2>/dev/null || echo Ubuntu`
GRUB_CMDLINE_LINUX_DEFAULT=""
GRUB_CMDLINE_LINUX=""

# If your computer has multiple operating systems installed, then you
# probably want to run os-prober. However, if your computer is a host
# for guest OSes installed via LVM or raw disk devices, running
# os-prober can cause damage to those guest OSes as it mounts
# filesystems to look for things.
#GRUB_DISABLE_OS_PROBER=false

# Uncomment to enable BadRAM filtering, modify to suit your needs
# This works with Linux (no patch required) and with any kernel that obtains
# the memory map information from GRUB (GNU Mach, kernel of FreeBSD ...)
#GRUB_BADRAM="0x01234567,0xfefefefe,0x89abcdef,0xefefefef"

# Uncomment to disable graphical terminal
#GRUB_TERMINAL=console

# The resolution used on graphical terminal
# note that you can use only modes which your graphic card supports via VBE
# you can see them in real GRUB with the command `vbeinfo'
#GRUB_GFXMODE=640x480

# Uncomment if you don't want GRUB to pass "root=UUID=xxx" parameter to Linux
#GRUB_DISABLE_LINUX_UUID=true

# Uncomment to disable generation of recovery mode menu entries
#GRUB_DISABLE_RECOVERY="true"

# Uncomment to get a beep at grub start
#GRUB_INIT_TUNE="480 440 1"

石头好可爱
